Electroformed photovoltaic printing mesh

Nantong Zhuolida specializes in precision electroformed PV printing stencils. Featuring precise openings, smooth grid lines and clog-free demolding, our durable stencils fit TOPCon, HJT and BC N-type cells, steadily improving solar cell conversion efficiency.

CONSULTATION

189-3869-3452 0513-8160 1666

PRODUCT DETAILS

PV Printing Stencil Precision Electroforming: Zhuolida’s Core Technology Empowering High-Efficiency PV Production

As the global photovoltaic industry accelerates iteration toward high-efficiency cells, large-scale production, and low-cost manufacturing, printing stencils has become a core process determining PV cell conversion efficiency and yield rate. PV printing stencils serve as the key tool for silver paste and aluminum paste printing on solar cells, where precision, surface finish and structural stability directly affect electrode uniformity, paste leakage and printing consistency. Traditional etching and laser-cut stencils struggle to meet the ultra-fine line width, high flatness and long-cycle durability requirements of modern PERC, TOPCon and HJT cell mass production. In this context, precision electroforming technology has become an indispensable core process for high-end PV printing stencils, and Nantong Zhuolida leads the industry with mature electroforming solutions to empower efficient and stable PV manufacturing.

Different from conventional subtractive manufacturing processes, Zhuolida’s PV printing stencils adopt advanced precision electroforming based on electrochemical additive deposition. This atomic-level molding technology delivers ultra-high dimensional accuracy, ultra-smooth hole walls and uniform overall tension that cannot be achieved by traditional processes. The stencil line width tolerance is strictly controlled within micron level, with smooth inner walls that ensure continuous and uniform paste outflow during high-speed printing. It effectively eliminates common production defects such as paste blockage, broken lines, paste overflow and uneven coating, greatly improving the printing qualification rate of PV cell electrodes.
52a6c6a697ce4571adb1633a3b47f8e3_6

Durability and batch consistency are the key pain points of PV mass production. Zhuolida optimizes the nickel-cobalt alloy electroforming formula and multi-stage pulse electroforming process, enabling printing stencils to feature high hardness, strong wear resistance and non-deformation stability. The enhanced material properties extend the service life of each stencil significantly, reducing frequent replacement downtime and lowering the overall production cost of PV manufacturers. All finished stencils undergo full-item precision inspection and flatness testing to ensure zero deviation in batch production, perfectly adapting to 24-hour continuous high-speed printing of modern PV production lines.

Supporting diversified customized production, Zhuolida provides one-stop tailored solutions for different PV cell types and printing processes. We quickly optimize stencil thickness, mesh opening structure and edge rounding according to customer drawings, fully compatible with TOPCon, HJT, IBC and other new-type high-efficiency photovoltaic cell printing requirements. With 18 years of precision electroforming experience and standardized quality management system, we realize rapid prototyping for new products and stable mass delivery, perfectly balancing high precision, high efficiency and cost control.

In the era of photovoltaic industry upgrading, precision printing tooling is a vital breakthrough point to improve cell conversion efficiency and reduce industrial costs. Adhering to technological innovation and quality supremacy, Nantong Zhuolida continuously optimizes precision electroforming craftsmanship, breaks through the precision bottlenecks of traditional PV stencil manufacturing, and provides high-reliability, high-precision printing stencil products for global photovoltaic enterprises. Committed to promoting the iterative upgrading of PV precision manufacturing technology, we help customers maximize production efficiency and product competitiveness in the fierce global photovoltaic market.

PRODUCT CHARACTERISTICS

HOT PRODUCT

: Electroformed Nickel Stencil

Electroformed nickel is a precision‑metal structure fabricated via electrochemical deposition with superior accuracy and consistency. High‑purity nickel deposits onto conductive substrates to form nickel layers with precise geometry and fine surface finish.

: Fever piece

The heating plate is a kind of electronic component that sheet can produce heat. It can convert electric energy into heat energy by using the principle that metal can generate heat after electrification. It has been widely used in the field of automobile and precision electronics.

: Corrosion of molybdenum

Molybdenum corrosion processing is used in various fields of national economy, such as aerospace and nuclear energy, lighting and electronic devices, vacuum furnace and protective atmosphere furnace, metal pressure processing glass industry, etc

: Etching net

Etching net refers to the use of corrosive liquid or laser engraving and other means, the metal plate etching, thus forming a hollow net.Used in integrated circuit printing, fluorescent screen electronic grille, precision filtration, microelectrode elements, etc.
